Manufactured by Narfoamkar
WET Barrel Hydrant
- Material: Cast Iron – Carbon steel
- Available size: 6" just for cast iron - 6", 4" for carbon steel
- Inlet connection: Flange ANSI #150 R.F. / F.F.
Outlet connections:
- 2 x 2 1/2" BS 336 Female Instantaneous Complete with Globe or Gate valve, Valve's Material: Gunmetal
- 1 x 4" or 5" or 5 1/2" Pumper connection in BS round Thread, Material: Gunmetal
- Working pressure: 18 bar
- Painted in Epoxy red RAL 3000 or RAL 3020
- ll needed accessories can be supplied (i.e. Reducer 6" x 4" for monitor connection, BFV in inlet of hydrant)
DRY Barrel Hydrant
- Material: Cast Iron
- Available size: 4", 6"
- Inlet connection: Flange ANSI #150 R.F. / F.F.
Outlet connections:
- 2 x 2 1/2" BS 336 Female Instantaneous Complete with Globe or Gate valve, Valve's Material: Gunmetal
- 1 x 4" or 5" or 5 1/2" Pumper connection in BS round Thread, Material: Gunmetal
- It is equipped with an anti-freeze Automatic drain that enables the Hydrant to be emptied when the valve is fully closed
- All the internal components are easy to dismantle and maintain.
- Working pressure: 16bar
- Painted in Epoxy red RAL 3000 or RAL 3020
- The monitor type is available also
- All needed accessories can be supplied (i.e. Elbow on foot, BFV in inlet of monitor in monitor type Hydrants)
