APPLICATIONS
• industrial and municipal fire brigades
• military
• marine fire fighting
• interior rack and reel hose
• commercial and civil engineering
FEATURES
• very lightweight and highly flexible (even at low temperature)
• small coil diameter
• excellent resistance to weathering and ozone
• inner lining excellent resistant to sea water and a wide range of chemicals
• mildew and rot proof
• easy to repair
CONSTRUCTION
Jacket:
• high tenacity multifilament polyester yarn, circular woven in twill weave
• 2F: 2-ply warp threads
• 3F: 3-ply warp threads, heavy duty construction for better abrasion resistance
Lining:
• high grade EPDM rubber, cold flexible, suitable also for hot water
• excellent resistance to sea water, a wide range of chemicals, UV and ozone
• coextruded CR rubber adhesive layer, penetrates during vulcanisation completely into the weaving structure
• this style of rubber lining guarantees a smooth inner tube with low friction loss and an excellent adhesion between lining and jacke
SPECIAL OPTIONS
• Single lengths longer than 30 m (100 ft)
25 – 75 mm up to 1,000 m (3,300 ft)
90 – 110 mm up to 500 m (1,650 ft)
• other dimensions
Note that special options are subject to a higher price and a minimum order of 1,000 m (3,300 ft) per dimension. Production short lengths and over or short production up to 10 % of the total order quantity have to be accepted. Please enquire for details!
